Home Use 1080P ISDB-T TV Receiver / Digital Terrestrial Receiver Set Top Box MPEG2 / MPEG4

Minimum Order Quantity : 500pcs Price : Negotiation
Packaging Details : Gift Box Delivery Time : 15days after payment be done
Payment Terms : L/C, T/T, Western Union Supply Ability : 3000pcs per month
Place of Origin: Guangdong, China (Mainland) Brand Name: OEM
Certification: CE/ROHS Model Number: RS-ISDBT3

Detail Information

ChipSet: RS-ISDBT3 PVR: Yes
JPEG: Yes Supports HDMI 1.3 (1080P): Yes
DVB-T2/DVB-T: Yes H.264: Yes
One USB 2.0 &HDML: Yes High Difinition: Yes
High Light:

isdb-t digital tv receiver

,

isdb-t set top box

Product Description

Full HD 1080P Digital Terrestrial Receiver ISDB-T TV Receiver  Box, ISDB-T Set Top Box





Description:

DVB-T2 tv box: ISDB
1.Support SD&HD MPEG-2/4
2.4000channels for TV & Radio
3.1080i/1080p/720p/576i/576p.
4.support OEM order

Superiorities:

1.Digital HD DVB-T2

3.MPEG-4/H.264
4.USB 2.0 &HDMI
5.PVR,view JPEG
6.1080p support





Specfication:

1. Supports all ISDB-T broadcast (1, 3, 13 segment), MPEG-2/MPEG-4 AVC/H.264 HD/SD Video , DiVX
2. Compatible with480i/480p/720p/1080i/1080p video formats
3. Auto and manually scan all available TV and radio channels
4. Aspect ratio 16:9 and 4:3, 1000 channels memory, parental control
5.HDMI, YPbPr, RCA, coaxial output
6. Teletext/ Bit Map subtitle, compliant with ETS1
7. Supported 7-Day EPG function, VBI Teletext, closed caption
8. Support 6MHz software setting
9. Auto/Manual Program search, Multi-language supported
10. USB 2.0 for PVR,Timeshift, Software upgrade, Multimeida Playback(music,photo and HD video)
11. Demodulation: QPSK / 16QAM / 64QAM/QPSK or DQPSK;OFDM Reception Channel:: 13CH-62CH
12. Digital reception covers VHF & HUF band

ISDB-T Tuner and demodulator(NMI120+MSB1400)
Input frequency: VHF 7-13 Ch(177.143MHz~213.143MHz,UHF 14-69 Ch(473.143MHz~803.143MHz)
Input level:-90 ~ -5dBm
Bandwidth:6 MHz
Input impedance:75 Ω

Channel Decoding
Wave form: COFDM
Demodulation: QPSK,16QAM,64QAM, QPSK or DQPSK
FEC: 1/ 2, 2/3, 3/4, 5/6. 7/8 Automatic
Mode: 2K, 4K, 8K
Guard: 1/4, 1/8, 1/16, 1/32

Demultiplexer
Standard: ISO/IEC13818-1, MPEG-4HE AAC
Input Max. bit stream rate: 23.420Mbps

Video Decoding
Standard: ISO/IEC 13818-2, MPEG-2 MP@ML, H.264
Aspect ratio: 4:3, 16:9
Video format: PAL / NTSC/ AUTO
Video resolution: 1080p/1080i/720p/576p/576i(PAL),1080p/1080i/720p/480p/480i(NTSC)





Packet content:



1 X Set-Top Box

1 X user manual

1 X Mini jack cable to RCA (A/V)

1 X Power adapter 5V 2A

1 X remote control

1 X retail box
