Dreambox 800 HD PVR DM800HD Cable Receiver Support CA VFD LAN For TV

Product Description

SPECIFICATIONS:

300MHz MIPS processor

Single-EPG (Electronic Program Guide):sortable by data or alphabetically

Automatic search for additional air dates of a show and easy recording them by timer

Multi-EPG:graphically and text-based

Timeshift

List of recordings:sortable by date or alphabetically and free choice of different views

Timer programming manually or by EPG

Individually configurable timers,e,g,single or recurring timers

DiSEqC 1.0/1.1/1.2/1.3(USALS)

Channel change in less than a second

Start wizard for initial setup

Pre-intalled service list for DVB-S

Support of favorite lists

l Full automatic channel scan

l DVB/teletext with level 2.5 support

l Easy expansion of base function with the use of plugins

l MP3 playback

l Skinable OSD in many languages

l Remote controllable via Web-interface and streaming of the TV-/Radio stations to any PC connected to the box  through network

l Linux operating system

l A smart card reader

l MPEG2/H.264 hardware decoder

l Pluggable tuner modules

l LED panel with instructions

l 64MFlash 256MRam

l Built-in 2.5-inch hard drive or eSATA

l 10/100M Ethernet port

l Two USB2.0 interface

l V24/RS232 interface

Technical parameter:
DBS-Tuner without DVB-S2

l European plug interface

l Frequency Range 950 -2150MHz

l Demodulation DVB-S(QPSK)

l Signal level -65dBm -25dBm

l DBS-Tuner Input Connector F-Type female

l Input impedance 75ohm

l Loop through interner loop trough

l AFC+/-Mhz

l DVB-S: Viterbirates:1/2, 2/3, 3/4,5/6,7/8,automatical adjustment(k=7)

l Roll-off Factor 35%

Video decoder:

l Video compression MPEG-2 and MPEG-1 compatible,H.264

l Video Formats 4:3 / 16:9

l Letterbox percolating for 4:3 TV-Device

Audio decoder:

l Audio compression MPEG-1&MPEG-2 layer I and II

l Audio Mode Stereo ,Dolby Digital

l Frequency:32kHz,44.1kHz,48KHz,16kHz,22.05kHz,24kHz

Analog output:

l Output level L/R 0.5 Vss on 600Ohm

l THD>60dB(1kH)

l Crosstalk<-65dB

Physical specification:

l Ambient Temperature +15C...+35C

l Humidity<80%

l Size(WxDxH):374mmx230mmx75mm

l Weight:2.2kg without HDD
